This KA-certified explosion-proof mine hazardous liquid transport vehicle is equipped with a Yunnei turbocharged diesel engine and part-time four-wheel drive configuration, complying with mine flammable liquid transportation safety specifications.

Products
CY-3000/5000 Diesel Trackless Fuel Transport Vehicle
CY-3000/5000 Diesel Trackless Fuel Transport Vehicle
CY-3000/5000 Diesel Trackless Fuel Transport Vehicle
CY-3000/5000 Diesel Trackless Fuel Transport Vehicle
CY-3000/5000 Diesel Trackless Fuel Transport Vehicle
CY-3000/5000 Diesel Trackless Fuel Transport Vehicle

CY-3000/5000 Diesel Trackless Fuel Transport Vehicle

    This KA-certified explosion-proof mine hazardous liquid transport vehicle is equipped with a Yunnei turbocharged diesel engine and part-time four-wheel drive configuration, complying with mine flammable liquid transportation safety specifications.

    It offers two standard tank capacities of 3000L and 5000L, specially used for centralized diesel supply and on-site refueling of mining equipment in open-pit and underground mines. The tanker adopts Q235B carbon steel material, with complete safety protection devices, and all refueling system configurations support customized adjustment.

Main Specification

Overall Dimensions

5580mm(L) × 2160mm(W) × 2500mm(H)

Wheelbase

2850 mm

Front/Rear Track

1650 mm

Number of Doors

2

Seating Capacity

2/3 seats

Fuel Tank Capacity

120 L

Curb Mass

4900 / 5100 kg

Gross Vehicle Mass

7420 / 9300 kg

Rated Tank Capacity3000/5000 L
Tank MaterialQ235B
Oil Pump Flow 30 m³/h

Maximum Gradeability

14°

Minimum Ground Clearance280 mm
Tire Specification8.25R16LT  18PR
Engine ModelYN35CCF4
Engine ManufacturerYunnei Power
Displacement3470 mL
Intake ModeTurbocharged
TransmissionWanliyang 5-speed Transmission
Rated Power/Speed85kW/2400r/min
Max. Torque/Speed414Nm/1440-1800r/min
Fuel TypeDiesel
4WD ModePart-time Four-wheel Drive
Front/Rear SuspensionLongitudinal Leaf Spring Non-independent Suspension
Steering SystemHydraulic Power Steering
Parking Brake Type

Spring Brake with Hydraulic Release

Environmental StandardGB20891-2014 Stage IV
Note: Other configurations can be CUSTOMIZED according to customer requirements.
