Diesel Fork Lift Truck 5 Ton

Chinese 5 Ton Electric Diesel Rough Terrain Fork Lift Truck Warehouse Forklift with Manufacturer Price

Linda

SF50
STANDARD DIMENSIONS
General	Model		SF50			unit
	Load capacity		5000			Kg
	load center		600			mm
	Power type		Diesel
Dimensions	Lift size		3000			mm
	Fork size		1220x175x50			mm
	Mast tilt angle		/6/12			°
	Front overhang		627			mm
	Overall dimensions	Length to face of fork	4690			mm
		Overall width	1995			mm
		Overall height fork lowered	2500			mm
		Overhead guard height	2450			mm
	Turning radius		3250			mm
Performance	travel speed(full load/no load)		26/28			Km/h
	Lift speed with load		500			mm/sec
	Max.gradeability		20			%
	Self weight		8183			Kg
Wheel&tires	Tires	Front	8.5-15-14PR
		Rear	8.5-15-14PR
	tread	Front	1470			mm
		Rear	1700			mm
	Wheelbase		2250			mm
	Min.ground clearance(mast)		200			mm
Drive units&control	Engine	Model	CHAOCHAI 6102BG	PERKINS 1104D	ISUZU 6BG1
		Rated output	81/2500	83/2200	82.4/2000	Kw/rpm
		Rated torque	353/1700	418/1400	416/1800	N·m/rpm
		No.of cylinder	6	4	6
		Bore×stroke	102×118	105×127	105/125	mm
		Displacement	5.795	4.4	6.494	L
