Double Cab Part-time 4WD Diesel Class II Off-road Chassis

Structure: Double cab 5-seat non-load-bearing off-road bare chassis, 3695mm long wheelbase with 225mm ground clearance for great trafficability.
Power: 2.36L high-torque diesel engine, dual National III / VI b emission standards, matched with 5MT & mechanical part-time 4WD.
Suspension & Brake: Front and rear leaf spring suspension, front disc rear drum brake equipped with standard ABS+EBD.
Full Standard Cabin Config: Manual AC, fabric seats, front USB, halogen headlights plus front & rear fog lamps.
Wide Application: Perfect chassis for refitting rescue, engineering, patrol and all kinds of special off-road vehicles.

Liorah

Basic Vehicle Parameters		Power & Drive System
Product Name	Class II Bare Chassis	Engine Model	YCY24165-66 / YCY24140-30A
Model	BAW2043HMS61D	Fuel Type	Diesel
Brand	Ruisheng	Emission Standard	National VI b / National III
Curb Weight	2200 Kg	Displacement	2360 mL
Gross Vehicle Weight	4465 Kg	Rated Power / Speed	120kW,103kW / 2950 r/min
Axle Load	1570 / 2895 Kg	Max Torque / Speed	350N·m / 1500-2400 r/min
Wheelbase	3695 mm	Transmission	5MT Manual Gearbox
Front/Rear Track	1540 mm	Drive Mode	Front-engine Part-time 4WD
Tire Spec	265/70R16LT 10PR;265/70R17LT 10PR	Transfer Case	Mechanical 2-speed Manual Shift
Overall Dimension(LWH)	5625×1830×1970 mm	Front Suspension	Longitudinal Leaf Spring Dependent Suspension
Min Ground Clearance	225 mm	Rear Suspension	Longitudinal Leaf Spring Dependent Suspension
Min Turning Diameter	16.1 m	Steering Assist	Mechanical Hydraulic Assist
Max Speed	120 Km/h	Body Structure	Non-load-bearing Body
Rated Passenger	5 persons (2+3)	Brake System	Front Disc + Rear Drum, ABS+EBD, Hand Parking Brake
Approach/Departure Angle	42° / 32°	Standard Lamp Configuration	Halogen Headlight, Front & Rear Fog Lamp
