PXAGV01 1 Ton Explosion-Proof Enclosed AGV with Automatic Roller Shutter

Products
1 Ton Explosion-Proof Enclosed AGV | Laser-Guided Automated Guided Vehicle with Roller Shutter Door
1 Ton Explosion-Proof Enclosed AGV | Laser-Guided Automated Guided Vehicle with Roller Shutter Door

1 Ton Explosion-Proof Enclosed AGV | Laser-Guided Automated Guided Vehicle with Roller Shutter Door

  • 1 Ton Payload in Explosion-Proof Design: Certified for use in hazardous environments with flammable gases and dusts.

  • Enclosed Cargo Box with Automatic Roller Shutter: Protects sensitive cargo while enabling fast, automated access.

  • High-Speed Operation: 15 km/h max speed ensures efficient material flow in industrial yards.

  • Laser + IMU Hybrid Navigation: Provides precise, reliable positioning in complex settings.

  • Dual Explosion-Proof Certification: Compliant with both gas (IIB) and dust (IIIC) hazardous area standards.

Main Specification

Model

PXAGV01(Explosion-proof)

Overall Dimensions

4500mm (L)  × 1700mm (W) × 2500mm (H)

Maximum Speed

15km/h (Automatic operation)

Maximum Gradeability

7°, fully loaded

Maximum Load

1T

Minimum Turning Radius

5m

Superstructure Type

Enclosed Cargo Box with Automatic Roller Shutter Door

Navigation Method

Laser + IMU

Battery Capacity

19.2kWh

Operating Range

30km

Explosion-proof RatingEx db eb ib mb s IIB T5 Gb / Ex ib mb s tb IIIC T100°C DbCertified for gas and dust hazardous areas
