PXAGV03EX 3 Ton Explosion-Proof Enclosed AGV with Roller Conveyor

Products
3 Ton Explosion-Proof Enclosed AGV | Laser-Guided Automated Guided Vehicle with Roller Conveyor
3 Ton Explosion-Proof Enclosed AGV | Laser-Guided Automated Guided Vehicle with Roller Conveyor

3 Ton Explosion-Proof Enclosed AGV | Laser-Guided Automated Guided Vehicle with Roller Conveyor

  • 3 Ton Payload in Explosion-Proof Design: Certified for use in hazardous environments with flammable gases and dusts.

  • Integrated Roller Conveyor & Automatic Door: Enables automated loading/unloading without manual intervention.

  • High-Speed Operation: Max speed of 15 km/h ensures efficient material flow.

  • Laser + IMU Hybrid Navigation: Provides precise, reliable positioning in complex industrial settings.

  • Dual Explosion-Proof Certification: Compliant with both gas (IIB) and dust (IIIC) hazardous area standards.

Main Specification

Model

PXAGV03EX(Explosion-proof)

Overall Dimensions

7400mm (L)  × 3400mm (W) × 3350mm (H)

Maximum Speed

15km/h (Automatic operation)

Maximum Gradeability

7°, fully loaded

Maximum Load

3T

Minimum Turning Radius

7m

Superstructure Type

Cargo Box + Roller Conveyor + Automatic Roller Shutter Door

Navigation Method

Laser + IMU

Battery Capacity

64.8kWh

Operating Range

30km

Explosion-proof RatingEx db eb ib mb IIB T5 Gb / Ex tb IIIC T95°C Db
