Brand:FAW | NEW J5P Concrete Mixer truck 8*4 | NEW J5P Concrete Mixer truck 8*4 | NEW J5P Concrete Mixer truck 8*4 |
Mass Parameter(kg) | Curb Weight | 12150 | 12150 |
Max. GVW | 31000 | 31000 | |
Dimension Parameter(mm) | Overall Dimension | 12093*2500*3075 | 12093*2500*3075 |
Wheelbase | 1350+3800+1350 | 13504000+1350 | |
Performance Parameter | Max. Speed(km/h) | 78 | 78 |
Economic Speed(km/h) | 50-60 | 50-60 | |
Max. Gradeability(%) | 52 | 52 | |
Cabin | NEW J5P 15 models Full floating flat top single lying | NEW J5P 15 models Full floating flat top single lying | |
Engine | Model | WP10.340E32 | WP10.380E32 |
Rated Power(kw/rpm) | 250/2200 | 279/2200 | |
Max. Torque(Nm/rpm) | 1350/1200-1600 | 1500/1200-2200 | |
transmission | Model | 9JSD135T | 12JS200T |
Gears | Manual transmission, 9 forward gears, 1 reverse gears | Manual transmission, 12 forward gears, 2 reverse gears | |
Axles | Steering Axle | maximum load 9000kg | maximum load12000kg |
Drive Axle | 300 hub reduction, reduction ratio 5.921, maximum load16000kg*2 | 300 hub reduction, reduction ratio 5.921, maximum load16000kg*2 | |
Body | Suitable for 12/13/14/15/16 m³ | Suitable for 12/13/14/15/16 m³ | |
stir body | stir body | ||
tyres | 12.00R20 18PR | 12.00R20 18PR | |
Emission Level | E2 | E2 | |
Certifications | |||
Remarks | |||
Recommend Market Type | Cargo Type | concrete | concrete |
Main Working Condition | Round trip full load | Round trip full load | |
Operating Condition | short distance | short distance | |
Driver Position | left (RHD can be optional) | left (RHD can be optional) | |
Customer Type | mid-to-high end, prefer quality and price | mid-to-high end, prefer quality and price |
