FAW J6P 8X4 390HP Tipper Dump Truck
FAW J6P 8×4 390HP CA6DM2 with exhaust brake for loaded climbs and safe descents. Large 25m³ 8mm-steel box cuts haul trips for sand, rock and aggregate. Twin 16T hub-reduction axles handle rough quarry roads; proven FAW 10-speed gearbox and easy African parts supply. J6P comfortable cabin, customizable, ideal for large construction & mining projects.
Products
FAW J6P 8X4 390HP Tipper Dump TruckFAW J6P 8×4 390HP CA6DM2 with exhaust brake for loaded climbs and safe descents. Large 25m³ 8mm-steel box cuts haul trips for sand, rock and aggregate. Twin 16T hub-reduction axles handle rough quarry roads; proven FAW 10-speed gearbox and easy African parts supply. J6P comfortable cabin, customizable, ideal for large construction & mining projects.
| Item | Specification |
|---|---|
| Model | CA3310P66K24L5TE |
| Vehicle Type | FAW J6P Tipper / Dump Truck, 8×4 (12 Wheels), LHD |
| Target Markets | Cameroon, Nigeria |
| Emission Standard | Customizable |
| Engine | FAWDE CA6DM2-39E3F, Inline 6-cyl Water-cooled, 390HP / 1750N.m, 11.04L, Exhaust Valve Engine Brake |
| Clutch | 430mm Diaphragm |
| Gearbox | FAW CA10TAX190M Twin-shaft, 10 Forward / 2 Reverse |
| Front Axle | FAW 2020, 9T |
| Rear Axle | FAW Φ300, 16T×2, Benz-tech Double Reduction Hub Reduction |
| Frame | 300×80×(8+8) Double Layer |
| Steering | Power-assisted |
| Dump Box | Inner 7600×2300×1450mm, 25m³; Bottom 8mm, Side 6mm; Front Tipping, Chinese Hydraulic Cylinder |
| Suspension | Leaf Spring 10/12/12, 4 U-bolts |
| Tire | Double Coin or Similar, 12.00R20-18PR Radial, ECE/GCC |
| Wheelbase | 1950+4150+1350mm |
| Overall Dimensions | 10600×2500×3300mm |
| Fuel Tank | 400L |
| Tare / Gross Weight | 18,400kg / 58,400kg |
