FAW J6P 8X4 Dump Truck 375HP
FAW J6P 8×4 12-wheeler dump truck, 375HP engine with 1550N.m torque for heavy bulk hauling. Four axles spread the payload for longer tire and axle life. Large 20.7m³ U-shaped box with 8mm hardened bottom resists aggregate wear; front tipping unloads cleanly. Desert air filter and fuel pre-filter protect the engine in dusty remote areas. SGS/BV certified, customizable.
The FAW J6P 8×4 dump truck is a high-capacity four-axle tipper built for heavy bulk hauling on roads and construction sites. Four axles spread the load across twelve wheels, carrying more payload than a standard 6×4 while reducing pressure on each tire and axle for longer component life.
The 375HP six-cylinder diesel delivers 1550N.m of torque, pulling fully loaded up long grades without strain while meeting common import emission rules. The FAST 12-speed gearbox with PTO drives the front-tipping hydraulics reliably, and the cast steel wheel reduction axles with 5.263 ratio give strong crawling power at the quarry face.
The 20.7m³ U-shaped box, built with an 8mm hardened steel bottom and 6mm sides, resists wear from aggregates and ore, while the rounded shape lets material slide out cleanly.
Desert air filter and fuel pre-filter protect the engine in dusty, low-fuel-quality regions; TRW steering and the full-floating A/C cabin keep drivers comfortable on long shifts. SGS/BV certified and customizable, this is a dependable high-volume tipper for contractors and bulk fleets.
| Item | Specification |
|---|---|
| Vehicle Type | FAW J6P Dump Truck, 8×4 |
| Emission Standard | Optional |
| Engine | FAW CA6DL2-37E5, Inline 6-cylinder Diesel, 375HP (279kW), 1550N.m, 8.6L |
| Gearbox | FAST 12JSD160T Manual, 12 Forward / 2 Reverse, With PTO |
| Clutch | Φ430mm |
| Axles | Dual Front Steering Axles + Dual Rear Drive Axles; Φ300 Cast Steel Wheel Reduction, Ratio 5.263 |
| Frame | 300×80×(8+8+5) |
| Cabin | J6P Fully Floating Flat-top Semi-cab, Auto A/C, LCD Instrument, Manual Window Lifter, Manual Mirror |
| Dump Box | U-shaped, 6000×2300×1500mm, 20.7m³; Bottom 8mm, Side 6mm |
| Lifting System | Front Tipping (Front Lift) |
| Tire | 315/80R22.5 Radial |
| Fuel Tank | 400L |
| Overall Dimensions | 9200×2500×3300mm |
| Extras | Iron Bumper, Desert Air Filter, Two-point Coil Spring Cab Suspension, Electro-hydraulic Lift, Raised Hydraulic Support, 180Ah Battery, TRW Steering Gear, Fuel Pre-filter Module, Speed Limiter 89km/h |
| Certification | ISO9001, 3C, SGS, BV |
