Drive System

6×4;  Left hand drive

Cabin

FAW JK6 flat cabin, one sleeper with A/C

Electric glass and rear view mirror; electric cabin lift;

Driver air seat; multi-functional steering wheel; cruise control

Engine

FAWDE diesel engine, EURO5, 6 cylinder, inter-cooling, turbocharging

Model: CA6DLD-26E5

Power: 260hp@2300rpm

Bore/Stroke: 108x120mm

Max. Torque: 1050N.m@1300-1700rpm

Gearbox

FAST GEAR; Manual gearbox, Model: 8JS125TA, max. input 1250N.m

8 forward speeds, 1 reverse speeds; with PTO (Power Take Off)

Dimensions (mm)

7900×2500×3450mm

Dump body (mm)

4850×2300×1300mm, 14.5m3

Thickness (mm)

Bottom 6mm, side 4mm; Mn Q345 steel

Tipping system

Front tipping system

Wheel base   (mm)

3300+1350mm

Curb weight (kgs)

11500

Payload (kgs)

20000

Frame (mm)

270*80*(7+5), strengthened double layer truck frame

Front Axle

A5S front axle, 5T loading capacity, drum brake

Rear Axle

12 Ton x 2 drive axle, ф435 welding axle;

Main ratio= 5.143

Spring suspension F/R

10/10

Clutch

Φ 430mm Diaphragm type

Tire

Tubeless radial tire: 12R22.5-16PR, 10+1 spare tire

Fuel Tank

200L

Battery

Maintenance free, 150Ah

Others

WABCO clutch booster/ Imported clutch/ WABCO valves/ABS
