Rated operating load

5000

kg

Bucket capacity

2.5~4.5

m³

Machine weight

17500±300

kg

Dump clearance at maximum lift

3100~3780

mm

Reach at maximum lift

1100~1220

mm

Wheel base

3300

mm

Tread

2250

mm

Max.breakout force

175±5

kN

Hydraulic cycle time-raise

6

s

Total hydraulic cycle time

10.5

s

Min. turning radius over tyres

5925±50

mm

Articulation angle

38

°

Gradeability

30

°

Tyre size

23.5-25-16PR

Overall machine dimension L×W×H

8225×3016×3515

Model

WD10G220E21

Rated Power

162

Kw

Travel speed

Ⅰ-gear(F/R)

13/17

km/h

Ⅱ-gear(F)

41

km/h

No further information of sample contents, product structure and configuration parameters updates.There maybe some difference between sample books and material objects.Please kind prevail.
