Hyundai HX205G is a 20-ton medium excavator with upgraded hydraulic system. It features strong digging force, low fuel consumption and reliable performance for municipal works, road construction and earthmoving projects.
Hyundai HX205G Medium Hydraulic Excavator
Hyundai HX205G is a 20-ton medium excavator with upgraded hydraulic system. It features strong digging force, low fuel consumption and reliable performance for municipal works, road construction and earthmoving projects.
Hyundai HX205G Medium Hydraulic Excavator
Hyundai HX205G is a new generation 20-ton class medium hydraulic excavator. It adopts optimized power and hydraulic matching technology to achieve lower fuel consumption while maintaining powerful digging capacity. The reinforced working device and chassis improve machine durability. The quiet, wide-view cab reduces operator fatigue during long shifts. It is widely applied in municipal renovation, road building, pipeline laying and general earthwork, being a cost-effective choice for contractors.
| Main Technical Specifications | |||
| Category | Parameter | Unit | Value |
| Engine | Manufacturer | - | Weichai |
| Model | - | WP4.6NG175E442 | |
| Emission Standard | - | China IV (Stage IV) | |
| Rated Power (Net) | kW/hp/ps/rpm | 129/2000 | |
| Max. Torque | N.m/rpm | 700/1400-1600 | |
| Displacement | cc | 4580 | |
| No. of Cylinders - Bore x Stroke | EA-mm | 4-108x125 | |
| Battery | EA-V x AH | 2-24x120 | |
| Starter Motor | V/kW | 24/4.5 | |
| Alternator | V/A | 28/80 | |
| Performance | Swing Speed | rpm | 10.6 |
| Swing Torque | kN.m | 85 | |
| Travel Speed | km/hr | 3.2/5.1 | |
| Gradeability | deg | 35 | |
| Max. Traction Force | ton | 21.8 | |
| Bucket Digging Force (ISO) | ton | 15.5 | |
| Arm Digging Force (ISO) | ton | 11.1 | |
| Working Device | Boom Length / OPT | mm | 5675 |
| Arm Length / OPT | mm | 2920 | |
| Bucket Capacity / OPT (SAE) | mm | 1 | |
| Dimensions | Overall Length | mm | 9765 |
| Overall Width | mm | 2880 | |
| Upper Structure Width (Body Width) | mm | 2740 | |
| Overall Height (Boom) | mm | 3080 | |
| Overall Height (Cab) | mm | 2980 | |
| Track Gauge | mm | 2200 | |
| Track Ground Contact Length (Wheelbase/Tread) | mm | 3370 | |
| Track Length | mm | 4175 | |
| Track Shoe Width (OPT) | mm | 600 | |
| Min. Ground Clearance | mm | 472 | |
| Counterweight Ground Clearance | mm | 1064 | |
| Tail Swing Radius / Tail Radius | mm | 3080 | |
| Oil Tank | Fuel Tank Capacity | L | 400 |
| Hydraulic Oil Tank Capacity (System) | L | 165/256 | |
| Engine Oil | L | 19 | |
| Working Range | Min Swing Radius | mm | 3646 |
| Max Digging Reach | mm | 9896 | |
| Max Digging Depth | mm | 6644 | |
| Max Digging Height | mm | 9474 | |
| Max Dump Height | mm | 6714 | |
