7 Ton New Diesel Forklift Truck

Lifting Equipment Heavy Forklift Price of Shantui Sf70 Diesel Pallet Truck 7 Ton

Linda

SF70
STANDARD DIMENSIONS
General	Model		SF70		unit
	Load capacity		7000		Kg
	load center		600		mm
	Power type		Diesel
Dimensions	Lift size		3000		mm
	Fork size		1220x175x50		mm
	Mast tilt angle		/6/12		°
	Front overhang		627		mm
	Overall dimensions	Length to face of fork	4840		mm
		Overall width	1995		mm
		Overall height fork lowered	2500		mm
		Overhead guard height	2450		mm
	Turning radius		3450		mm
Performance	travel speed(full load/no load)		26/28		Km/h
	Lift speed with load		450		mm/sec
	Max.gradeability		20		%
	Self weight		9400		Kg
Wheel&tires	Tires	Front	8.5-15-14PR
		Rear	8.5-15-14PR
	tread	Front	1470		mm
		Rear	1700		mm
	Wheelbase		2250		mm
	Min.ground clearance(mast)		200		mm
Drive units&control	Engine	Model	CHAOCHAI 6102BG	PERKINS 1104D
		Rated output	81/2500	83/2200	Kw/rpm
		Rated torque	353/1700	418/1400	N·m/rpm
		No.of cylinder	6	4
		Bore×stroke	102×118	105×127	mm
		Displacement	5.795	4.4	L
