Three-door Ten-seat Mining Personnel Carrier KA-certified Explosion-proof Underground Mine Safety Vehicle

Products

This KA-certified explosion-proof underground mine safety vehicle is equipped with an Isuzu turbocharged diesel engine and part-time four-wheel drive system, fitted with hydraulic wet brake to eliminate spark risks and comply with underground mine safety standards. This 10-seat mining passenger vehicle serves for large-scale staff transportation and mine safety inspection in coal and metal mines, with all vehicle configurations customizable to meet diverse working demands.

Liorah

13780658694

+8613780658694

liorah@charymachinery.com

Inquiry List Add To Inquire Vehicle

Main Specification
Overall Dimensions	≤ 4730mm(L) × 1820mm(W) × 2130mm(H)
Wheelbase	2800 mm
Front/Rear Track	1540 mm
Number of Doors	3
Seating Capacity	10 seats
Fuel Tank Capacity	45 L
Curb Mass	2340 kg
Gross Vehicle Mass	3340 kg
Maximum Gradeability	14°
Maximum Traction Force	≥20 kN
Minimum Turning Radius (Outer Edge)	7.55 m
Minimum Ground Clearance	240 mm
Tire Specification	7.50-16LT
Engine Model	4KH1-TCF40
Engine Manufacturer	ISUZU (China) Engine Co., Ltd.
Displacement	2999 mL
Intake Mode	Turbocharged
Transmission	3-speed Manual
Rated Power/Speed	95kW/2900r/min
Max. Torque/Speed	320Nm/1700-2800r/min
Fuel Type	Diesel
4WD Mode	Part-time Four-wheel Drive
Front/Rear Suspension	Leaf Spring Non-independent Suspension
Steering System	Hydraulic Power Steering
Front/Rear Brake Type	Hydraulic Wet Brake
Parking Brake Type	Spring Brake with Hydraulic Release
Note: Other configurations can be CUSTOMIZED according to customer requirements.
