Warrior Series Four-door Fifteen-seat Mining Personnel Carrier RU-15(D)/(E) KA-certified Explosion-proof Underground Mine Safety Vehicle

Products

This KA-certified explosion-proof underground mine safety vehicle adopts an Isuzu turbocharged diesel engine and part-time four-wheel drive system, equipped with hydraulic wet brake to meet strict underground explosion-proof standards. This high-capacity 15-seat mining passenger vehicle is designed for large-group staff transportation and mine safety patrol in coal and metal mines, with all configurations available for customized adjustment.

Liorah

13780658694

+8613780658694

liorah@charymachinery.com

Inquiry List Add To Inquire Vehicle

Main Specification
Overall Dimensions	≤ 5830mm(L) × 1920mm(W) × 2150mm(H)
Wheelbase	3695 mm
Front/Rear Track	1540 mm
Number of Doors	4
Seating Capacity	15 seats
Fuel Tank Capacity	45 L
Curb Mass	2770 / 2860 kg
Gross Vehicle Mass	4270 / 4360 kg
Maximum Gradeability	14°
Maximum Traction Force	≥20 kN
Minimum Turning Radius (Outer Edge)	8.935 m
Minimum Ground Clearance	240 mm
Tire Specification	LT265/70R17
Engine Model	4KH1-TCF40
Engine Manufacturer	ISUZU (China) Engine Co., Ltd.
Displacement	2999 mL
Intake Mode	Turbocharged
Transmission	3-speed Manual + 1-speed Automatic
Rated Power/Speed	95kW/2900r/min
Max. Torque/Speed	320Nm/1700-2800r/min
Fuel Type	Diesel
4WD Mode	Part-time Four-wheel Drive
Front/Rear Suspension	Leaf Spring Non-independent Suspension
Steering System	Hydraulic Power Steering
Front/Rear Brake Type	Hydraulic Wet Brake
Parking Brake Type	Spring Brake with Hydraulic Release
Note: Other configurations can be CUSTOMIZED according to customer requirements.

Inquiry Sheet

Inquiry

If you have any questions about the product, please fill in the form below and we will contact you as soon as possible.

This KA-certified explosion-proof underground mine safety vehicle adopts an Isuzu turbocharged diesel engine and part-time four-wheel drive system, equipped with hydraulic wet brake to meet strict underground explosion-proof standards.
