Engine | |
Model | KTA19-C525 or QSX15 |
Type | Inline, 6-cylinder, turbocharged, water-cooled |
Flywheel power, kW | 316 |
Rated speed, r/min | 1800 |
Transmission system | |
Torque converter | 3-element, single-stage, single-phase |
Transmission | Hydraulic shift, planetary gear, hydraulic-actuated, multiple-disc clutch, forced lubrication, 3 forward and 3 reverse speeds |
Bevel gear | Helical bevel gear, one reduction, splash lubricated |
Steering clutch | Wet, multiple-disc, spring loaded, hydraulically operated and released |
Steering brake | Wet, band brake, operated with hydraulic booster and valve inner linkage |
Final drive | Spur gear, double reduction, splash lubricated |
Travel speed, km/h | |
Forward: | |
1st | 3.9 |
2nd | 6.7 |
3rd | 12.2 |
Reverse: | |
1st | 4.8 |
2nd | 8.5 |
3rd | 15.1 |
Under carriage | |
Sprocket | Segmented |
Track tension | Hydraulic-adjusted |
